Pavement Core Drilling Machine

The Pavement Core drilling machine, petrol engine powered road building drill has been designed specifically for the purpose of drilling test cores from or holes in roads, airport runways, bridges. The Machine comprises of two vertical support columns which carry the drill head/engine assembly accurately with the help of screwed spindle

Request a Quote WhatsApp Now
Category: Tag: Brand:

Description

The 6HP petrol engine with pulley mechanism works with minimum vibrations. The double precision bit advances with screwed spindle which provides a constant, accurate drill pressure, minimum core chipping & long bit life. The complete assembly is supplied on a rigid metal base with levelling facility and is suitable for vertically down coring applications only.

Bit diameter : 150mm

Maximum depth of core: 400mm

Drill Speed : Variable speed from 900 to 1200rpm

Drive  : 6HP Petrol Engine

Guide Shafts  : 40mm dia

Screwed Spindle  : 20mm dia

Water Tap  : 12mm

Drill Wrench  : Included

Ordering Details

Model          Description
AIS-433 Pavement Core Drilling Machine with Diamond Core Bits, 100mm dia x 400mm long
AIS-43301 Diamond Core Bits, 150mm dia x 400mm long
AIS-43302 Diamond Core Bits, 75mm dia x 400mm long

Additional information

Material Type

Asphalt Testing
