Description
| Technical Parameter | Details |
|---|---|
| Display | Large key-catching 7” Touch Screen Display with user-friendly operation. |
| Load Least Count | 0.1 kN |
| Pumping Type | Servo Controlled Closed Loop System. |
| Automatic Load Release | Automatic load release after test completion through software-controlled solenoid valve. |
| Hydraulic System | Double-stage hydraulic pump with automatic rapid approach and precise oil flow control. |
| Standards | As per IS:14858 (2000), IS:516 and calibrated with ±1% accuracy as per IS:1828 (Class 1). |
| Pace Rate | Controllable pace rate from 1 kN/sec to 10 kN/sec. |
| Connectivity | Access machine data on PC and Android Smartphones through WiFi internet and machine controller WiFi. |
| Graph Generation | Automatic Load vs Time graph generation directly on Touch Display in PDF format with complete details. |
| Report Management | Facility to store all test reports in Excel format including Date-Time, Test Number, Pace Rate, Peak Load, Stress in N/mm² and Kg/cm². |
| PDF Report | Direct PDF report saving with Load/Time graph and complete test details after test completion. |
| WiFi Printing | Direct PDF report printing support through WiFi printers from Touch Display. |
| Shape & Area Calculation | Facility to insert different specimen shapes and area values for direct calculation in N/mm² and Kg/cm². |
| Calibration | Machine calibration at minimum 8 points up to full machine capacity. |
| Remote Assistance | Internet connectivity support for remote online assistance. |
| Android App Access | Optional Android phone application access through WiFi. |
| Loading Frame | Fully welded solid all-plate type heavy-duty loading frame. |
| Platen Details | 300 mm diameter platen with 55 HRC hardness and 0.03 mm flatness tolerance. 325 mm gap between platens and 340 mm gap between plates. |
