Standard Tar Viscometer
Standard Tar Viscometer - Image 2

Standard Tar Viscometer

Model Description
AI-448 Standard Tar Viscometer, 10 mm Cup and Ball Valve
AI-449 Standard Tar Viscometer, 4 mm Cup and Ball Valve
AI-44501 Thermometer IP 8C, Range: 0°C to 45°C
AI-44502 Thermometer IP 9C, Range: 40°C to 85°C
AI-44503 Thermometer IP 10C, Range: 76°C to 122°C
Request a Quote WhatsApp Now
Category: Brand:

Description

Section Description
Reference Standards IS:1206, IP 72, STPTC RT 2, RT 3, BS:2000 (Part 72)
Application Used for determining the viscosity of cutback bitumen and road oil.
Construction Features
  • Chrome plated copper bath with drain valve.
  • Central tube provided to receive the test cup and position the stirrer.
  • Mounted on stand with levelling feet.
  • Stirrer fitted with curved shield and insulated handle.
  • Provided with thermometer socket and swivel support for valve.
  • Supplied complete with cup and ball valve as per model requirement.
Models Available
Model Description
AI-448 Standard Tar Viscometer with electrical heating, immersion heating elements and dimmerstat for temperature control. Complete with 10 mm cup and valve.
AI-449 Standard Tar Viscometer with electrical heating similar to AI-448, but supplied with 4 mm cup and valve.
Power Supply Suitable for operation on 220V, 50 Hz, Single Phase AC supply.

Additional information

Material Type

Asphalt Testing
